20 W Power Amplifier Circuit with high Quality Out put


Simple high power FM transmitter Circuit with 2N2222


This circuit is a simple two transistors (2N2222) . No license is required for this transmitter. If powered by a 9 volt battery and used with an antenna no longer than 12 inches, the transmitter will be within the FCC limits. The microphone is amplified by Q1. Q2, C5, and L1 form an oscillator that operates in the 80 to 130 MHz range.

Thursday, January 20, 2011

Numeric Water Level Indicator Circuit


The numeric water level indicator circuit works off 5V regulated power supply. It is built around priority encoder IC 74HC147 (IC1), BCD-to-7-segment decoder IC CD4511 (IC2), 7-segment display LTS543 (DIS1) and a few discrete components.
